Omron K3MA‑L‑C Process Digital Indicator

Omron K3MA‑L‑C Process Digital Indicator

The Omron K3MA‑L‑C is a compact digital indicator designed for accurate display of analog signals in industrial applications. It accepts standard voltage and current inputs (0–10 V, 4–20 mA, etc.) and features a high‑visibility red LED display.

This model operates on 24 VAC/VDC, making it compatible with most modern control panels. Its robust construction and 1/8 DIN format allow easy integration into panel‑mounted installations.

Main Features

• Brand: Omron
• Model: K3MA‑L‑C
• Type: Process digital indicator
• Format: 1/8 DIN (96 × 48 mm)
• Analog inputs: 0–20 mA, 4–20 mA, 0–5 V, 1–5 V, 0–10 V
• Display resolution: ±19,999
• Display: High‑brightness red LED
• Power supply: 24 VAC / 24 VDC
• Output: 1 relay (C version)
• Accuracy: ±0.1% FS
• Operating temperature: –10…+55 °C
• Mounting: Panel‑mount, 1/8 DIN
• Installation depth: approx. 80 mm
• Certification: CE

Condition

• Very good visual condition
• Fully functional
• Tested and operational
• Ready for immediate commissioning

Applications

• Display of 4–20 mA or 0–10 V analog signals
• Industrial process monitoring
• Production machinery
• Automation and control systems
• Monitoring of pressure, temperature, level, or flow (via transmitter)
